Fantech Dom Wall Mounted Exhaust Fan - 100MM / 125MM / 150MM
Description
Description
The Fantech Dom Series Wall Mounted Exhaust Fans are a European-made range of low-cost, high-performance ventilation solutions, specifically designed for domestic settings across Australia. Ideal for bathrooms, toilets, and laundries, these fans deliver reliable extraction with minimal noise, making them a preferred choice for both DIYers and professional installers.
With spigot sizes available in 100MM, 125MM, and 150MM, this versatile series caters to the most common ducting sizes in Australian homes. Engineered for easy installation and maintenance, the Dom series combines performance with practicality.
Whether youre ventilating a compact ensuite or a large laundry room, theres a Dom model tailored to your airflow needs.
Features
- Durable Construction: Made from tough, injection moulded plastic for long-lasting performance.
- Popular Sizing Options: Available in 100mm, 125mm, and 150mm spigot sizes.
- Energy Efficient: Low wattage motors (14W-23W) reduce power consumption while maintaining high performance.
- Backdraft Protection: Includes a low-loss foil backdraft damper to prevent cold air infiltration.
- Visual Feedback: Comes with a handy operating light indicator.
- Easy Maintenance: Removable front grille allows for simple and quick cleaning.
- Motor Safety: Built-in internal thermal cut-out ensures added protection against overheating.
Specifications
Specifications
Model No. | Air Flow (m³/h) | Air Flow (L/sec) | Fan Speed (RPM) | Avg. dB(A) | Power (Watts) | Voltage (V) |
---|---|---|---|---|---|---|
DOM-100C | 85 | 24 | 2500 | 34 | 14 | 230–240 |
DOM-125C | 180 | 50 | 2500 | 39 | 18 | 230–240 |
DOM-150C | 255 | 71 | 2200 | 40 | 23 | 230–240 |
What's in the box
What's in the box
[1] x Fantech Dom Wall Mounted Exhaust Fan - 100MM / 125MM / 150MM
Downloads
Downloads
Specification Sheet - Click Here
