Fantech Jetline Eco In-line Duct Mounted EC Exhaust Fan - 100MM (4" Inch)
Air Flow 260 M³/H | Power Consumption 19W | IP44
Fantech Jetline Eco In-line Duct Mounted EC Exhaust Fan - 100MM (4&...
Product Overview
| Model Number | JETLINE-100ECO |
| Airflow (M³/H) | 260 |
| Duct Flange Size | 100MM (4" Inch) |
| Motor Type | EC |
| Exhaust Fan Power (W) | 19 |
| Noise Level | 35 dBA at 3M |
| IP Rating | IP44 |
| Power Cord | No - Installation must be carried out by a qualified electrician. |
| Voltage | 240V - 1 Phase |
| Humidistat | No |
| Thermostat | No |
| Speeds / Control | PWM (0–10V) Control |
| Smart Control (Wi-Fi/App) | No |
| Run On Timer | Optional |
| Warranty | Fantech - 5 Years Warranty* |
Description
Description
The Fantech Jetline Eco 100MM In-line Duct Mounted EC Exhaust Fan is engineered with the latest energy efficient EC motor technology, delivering powerful airflow with minimal energy use. Designed for both residential and light commercial ventilation applications, this model combines a compact low-profile body with silent-block motor mounting that significantly reduces vibration and noise.
Featuring a high performance patented centrifugal impeller and a galvanised steel casing, the Jetline Eco ensures durability and long-lasting performance. The integrated 0-10V analogue speed control (with on-board potentiometer) makes it flexible for a wide range of ducted installations.
With quick fit galvanised steel mounting brackets and rubber gaskets on spigots for secure sealing, this fan is easy to install and can be mounted in any position. Perfect for Australian homes, apartments, and small commercial spaces where quiet, efficient ventilation is essential.
Note: This product requires hard wire installation by a licensed electrician.
Features
Features
- Energy Efficient EC Motor - Delivers maximum airflow with low power consumption
- Speed Controllable - 0-10V analogue input with on-board potentiometer
- Low Noise Operation - Silent-block motor mounting reduces vibration and sound
- Durable Casing - Manufactured from long-lasting galvanised steel
- High Performance Impeller - Patented centrifugal design for reliable airflow
- Quick Fit Brackets - Galvanised steel mounting system for easy installation
- Improved Seal - Rubber gasket on spigots for airtight duct connection
- Flexible Installation - Can be mounted in any position
Specifications
Specifications
- Model No: JETLINE-100ECO
- Air Flow: 260 M³/H
- L/Sec: 72
- Fan Speed: 45 Rev/Sec
- Noise Level: 35 dB(A) @ 3M
- Power Consumption: 19W
- Amps: 0.1
- Voltage: 220-240V
- IP Rating: IP44
- Flange Size: 100MM (4" Inch)
- Weight: 2.5 KG
What's in the box
What's in the box
- [1] x Fantech Jetline Eco In-line Duct Mounted EC Exhaust Fan - 100MM (4" Inch)
