Fantech Jetline Eco In-line Duct Mounted EC Exhaust Fan - 200MM (8" Inch)

The Jetline EcoWatt in-line fan comes equipped with the latest energy efficient EC motor technology. It is speed-controllable via a 0-10V analogue input signal and includes an on-board potentiometer.

It features a low profile design and silent-block motor mounting to reduce vibrations and lower the sound level of operation.

The Jetline EcoWatt has a durable outer casing that is manufactured from long lasting galvanised steel.

• An energy efficient solution with state-of-the-art EC motor technology.
• Speed-controllable via a 0-10V analogue input signal.
• High performance patented centrifugal impeller.
• Designed for direct connection to standard diameter circular ducting.
• Galvanised steel quick fit mounting bracket for fast installations.
• Rubber gasket on spigots improves seal between fan and duct work.
• Can be mounted in any position.
• Please note: requires hard wire installation

• Model Number: JETLINE-200ECO
• Airflow: 1050 m³/h (292 L/s)
• Fan Speed: 44 rev/sec
• Average Noise @ 3m: 51 dB(A)
• Power: 125 W
• Current: 0.5 A (1PH)
• Voltage: 220–240 V

• [1] x Fantech Jetline Eco In-line Duct Mounted EC Fan - 200MM (8" Inch) | 125W | 1050 M³/H | IP44

• Specification Sheet - Click Here
