Fantech Jetline Eco In-line Duct Mounted EC Exhaust Fan - 315MM (12" Inch)
Air Flow 1570 M³/H | Power Consumption 215W | IP44
Fantech Jetline Eco In-line Duct Mounted EC Exhaust Fan - 315MM (12...
Product Overview
| Model Number | JETLINE-315ECO |
| Airflow (M³/H) | 1570 |
| Duct Flange Size | 315MM (12" Inch) |
| Motor Type | EC |
| Exhaust Fan Power (W) | 215 |
| Noise Level | 52 dBA at 3M |
| IP Rating | IP44 |
| Power Cord | No - Installation must be carried out by a qualified electrician. |
| Voltage | 240V - 1 Phase |
| Humidistat | No |
| Thermostat | No |
| Speeds / Control | PWM (0–10V) Control |
| Smart Control (Wi-Fi/App) | No |
| Run On Timer | Optional |
| Warranty | Fantech - 5 Years Warranty* |
Description
Description
The Fantech Jetline Eco 315MM In-line Duct Mounted EC Exhaust Fan is the largest in the Jetline Eco range, designed to deliver powerful ventilation for large residential areas, commercial buildings, and industrial projects. With an impressive 1570 M3/H airflow, this fan uses advanced EC motor technology to ensure energy efficiency while maintaining high capacity performance.
Built with a robust galvanised steel outer casing, the Jetline Eco 315MM is made for durability in demanding environments. Its silent-block motor mounting significantly reduces vibration and noise, while the patented centrifugal impeller ensures consistent, efficient airflow even through long duct runs.
Featuring 0-10V analogue speed control and an on-board potentiometer, the fan allows full flexibility to match varying ventilation needs. Quick fit mounting brackets and rubber gaskets make installation simple, secure, and airtight. Suitable for mounting in any orientation, this unit is the ideal solution for large-scale ventilation.
Note: Hard wire installation by a licensed electrician is required.
Features
Features
- High Airflow Output - 1570 M³/H for large scale ventilation
- Energy Efficient EC Motor - Reduces running costs with reliable power
- Speed Controllable - 0-10V analogue input with on-board potentiometer
- Low Noise Design - Silent-block motor mounting minimises sound and vibration
- Durable Casing - Manufactured from galvanised steel for long service life
- Patented Centrifugal Impeller - Ensures consistent and efficient airflow
- Quick Fit Mounting Brackets - Easy installation with galvanised steel hardware
- Improved Seal - Rubber gaskets for airtight duct connections
- Flexible Orientation - Can be mounted in any position
Specifications
Specifications
- Model No: JETLINE-315ECO
- Air Flow: 1570 M³/H
- L/Sec: 436
- Fan Speed: 43 Rev/Sec
- Noise Level: 52 dB(A) @ 3M
- Power Consumption: 215W
- Amps: 0.9
- Voltage: 220-240V
- IP Rating: IP44
- Flange Size: 315MM (12" Inch)
- Weight: 9.6 KG
What's in the box
What's in the box
- [1] x Fantech Jetline Eco In-line Duct Mounted EC Fan - 315MM (12" Inch) | 215W | 1570 M³/H | IP44
