Fantech Aeromini ZOO (Zone Of Occupancy) Destratification AC Fan w/ Grille - ZFH15G | 250MM
Air Flow 936 M³/H | Power Consumption 60W | IP44
Product Overview
| Model Number | ZFH15G |
| Airflow (M³/H) | 936 |
| Motor Type | AC |
| Exhaust Fan Power (W) | 60 |
| Noise Level | 48 dBA at 3M |
| IP Rating | IP44 |
| Voltage | 240V - 1 Phase |
| Speeds / Control | Optional |
| Warranty | Fantech - 2 Years warranty |
Description
Description
The Fantech Zoo Destratification Fan ZFH15G is a compact and efficient air circulation solution designed to eliminate temperature stratification by drawing warm air from ceiling level and gently directing it back into occupied areas. This process improves indoor comfort while helping to reduce heating system energy consumption and operating costs.
Part of the innovative ZOO (Zone Of Occupancy) Series, the ZFH15G features a reliable AC external rotor motor that delivers consistent airflow performance and speed-controllable operation. By creating a precise column of air, the fan promotes better heat distribution throughout commercial and industrial spaces, helping maintain a more balanced indoor climate.
The fan is supplied with integrated finger guards on both the inlet and outlet, providing additional safety protection for installations where the fan may be mounted at lower heights. Constructed from fire-resistant ABS injection moulded plastic and fitted with a robust powder-coated steel handle and galvanised eye bolts, the ZFH15G is built for durability and easy installation.
Ideal for warehouses, retail stores, offices, workshops, factories, and commercial facilities, the Fantech ZFH15G Destratification Fan provides an effective and economical solution for improving comfort, reducing energy waste, and optimising heating system performance.
Features
Features
- Destratification Technology - Draws warm air from ceiling level and redistributes it into occupied spaces.
- Reduces Heating Costs - Improves heat distribution and increases heating system efficiency.
- 250mm Compact Design - Suitable for commercial and industrial air circulation applications.
- Integrated Finger Guards - Guards fitted on both inlet and outlet for enhanced safety.
- Speed Controllable AC Motor - Allows airflow adjustment to suit building requirements.
- Adjustable Airflow Direction - Pivoting handle enables quick targeting of specific areas.
- Fire Resistant Construction - Manufactured from durable fire-resistant ABS injection moulded plastic.
- Easy Installation - Supplied with galvanised eye bolts for simple hanging cable installation.
- Auto Reset Thermal Protection - Provides additional motor protection and reliability.
- Suitable for Commercial Buildings - Ideal for warehouses, workshops, offices, factories, and retail spaces.
Specifications
Specifications
| Specification | ZFH15G |
|---|---|
| Model | ZFH15G |
| Series | Zoo Destratification Fan |
| Fan Size | 250 mm |
| Motor Type | External Rotor Squirrel Cage AC Induction Motor |
| Voltage | 230V Single Phase |
| Frequency | 50/60Hz |
| Power Input | 0.06 kW |
| Current Draw | 0.28 A |
| Speed | 23 rps |
| Noise Level | 48 dB(A) @ 3m |
| Maximum Operating Temperature | 60°C |
| Approximate Weight | 4 kg |
| Motor Protection | IP44 |
| Thermal Protection | Auto Reset Thermal Protection |
| Finger Guards | Included |
What's in the box
What's in the box
- [1] x Fantech Aeromini ZOO (Zone Of Occupancy) Destratification AC Fan w/ Grille - ZFH15G | 250MM
