Fantech  |  SKU: ZFAN10004

Fantech Aeromini ZOO (Zone Of Occupancy) Destratification AC Fan w/ Grille - ZFH15G | 250MM

Air Flow 936 M³/H | Power Consumption 60W | IP44

$969.95
Stock Availability (LIVE)

Online:
Click & Collect

Lidcombe:

Product Overview
Model Number ZFH15G
Airflow (M³/H) 936
Motor Type AC
Exhaust Fan Power (W) 60
Noise Level 48 dBA at 3M
IP Rating IP44
Voltage 240V - 1 Phase
Speeds / Control Optional
Warranty Fantech - 2 Years warranty

Description

The Fantech Zoo Destratification Fan ZFH15G is a compact and efficient air circulation solution designed to eliminate temperature stratification by drawing warm air from ceiling level and gently directing it back into occupied areas. This process improves indoor comfort while helping to reduce heating system energy consumption and operating costs.

Part of the innovative ZOO (Zone Of Occupancy) Series, the ZFH15G features a reliable AC external rotor motor that delivers consistent airflow performance and speed-controllable operation. By creating a precise column of air, the fan promotes better heat distribution throughout commercial and industrial spaces, helping maintain a more balanced indoor climate.

The fan is supplied with integrated finger guards on both the inlet and outlet, providing additional safety protection for installations where the fan may be mounted at lower heights. Constructed from fire-resistant ABS injection moulded plastic and fitted with a robust powder-coated steel handle and galvanised eye bolts, the ZFH15G is built for durability and easy installation.

Ideal for warehouses, retail stores, offices, workshops, factories, and commercial facilities, the Fantech ZFH15G Destratification Fan provides an effective and economical solution for improving comfort, reducing energy waste, and optimising heating system performance.

Features

  • Destratification Technology - Draws warm air from ceiling level and redistributes it into occupied spaces.
  • Reduces Heating Costs - Improves heat distribution and increases heating system efficiency.
  • 250mm Compact Design - Suitable for commercial and industrial air circulation applications.
  • Integrated Finger Guards - Guards fitted on both inlet and outlet for enhanced safety.
  • Speed Controllable AC Motor - Allows airflow adjustment to suit building requirements.
  • Adjustable Airflow Direction - Pivoting handle enables quick targeting of specific areas.
  • Fire Resistant Construction - Manufactured from durable fire-resistant ABS injection moulded plastic.
  • Easy Installation - Supplied with galvanised eye bolts for simple hanging cable installation.
  • Auto Reset Thermal Protection - Provides additional motor protection and reliability.
  • Suitable for Commercial Buildings - Ideal for warehouses, workshops, offices, factories, and retail spaces.

Specifications

Specification ZFH15G
Model ZFH15G
Series Zoo Destratification Fan
Fan Size 250 mm
Motor Type External Rotor Squirrel Cage AC Induction Motor
Voltage 230V Single Phase
Frequency 50/60Hz
Power Input 0.06 kW
Current Draw 0.28 A
Speed 23 rps
Noise Level 48 dB(A) @ 3m
Maximum Operating Temperature 60°C
Approximate Weight 4 kg
Motor Protection IP44
Thermal Protection Auto Reset Thermal Protection
Finger Guards Included

What's in the box

  • [1] x Fantech Aeromini ZOO (Zone Of Occupancy) Destratification AC Fan w/ Grille - ZFH15G | 250MM
