Oerre Turbo Centrifugal Inline AC Fan - 100MM (4" Inch) | w/ Metal Casing

The Oerre Turbo Centrifugal Inline AC Fan 100MM with metal casing is a compact high pressure solution for moving air through long or restrictive duct runs. Delivering up to 270 M3/H, this Italian-made centrifugal inline fan is ideal for bathrooms, laundries, kitchens, offices and light commercial applications where a standard axial fan struggles.

The robust zinc-plated steel casing and ball bearing motor are built for continuous use, while the IPX4 rating and double-insulated design suit demanding Australian installations. With a 100MM (4" Inch) spigot and integrated mounting bracket, it is fast to install in tight roof spaces or plant areas.

Tradies and builders will appreciate the strong 294 Pa pressure performance and 60W motor that holds capacity against bends, joins and duct accessories. Pair with quality duct, vents and a speed controller for a reliable inline exhaust system that is easy to service and maintain. Add this Oerre Turbo 100 centrifugal inline fan to your cart today.

• High-pressure performance - 270 M³/H centrifugal inline fan suited to long or restrictive duct runs.
• Durable metal casing - zinc-plated steel housing for commercial-grade reliability on-site.
• Standard 100MM connections - 100MM (4" Inch) duct spigots to suit common residential and light commercial duct.
• Efficient ball bearing motor - 60W motor at approximately 2600 RPM for strong airflow and long service life.
• Moisture resistant - IPX4 rated and double insulated for bathrooms, laundries and similar wet areas.
• Easy installation - integrated mounting bracket for fast fixing in roof spaces and plant rooms.
• High temperature capability - handles extracted air up to 55°C for demanding ventilation applications.
• System-friendly - works with speed controllers, backdraft shutters and standard inline ventilation accessories.

• Brand: Oerre
• Model: Turbo 100
• Type: Centrifugal inline AC exhaust fan
• Air Flow: 270 M³/H (free air)
• Max Static Pressure: 294 Pa (30 mm H₂O)
• Power Consumption: 60W
• Voltage: 220-240V AC
• Frequency: 50 Hz
• Motor: Single-phase, 2-pole, ball-bearing centrifugal motor
• Motor Speed: 2600 RPM
• Nominal Current: 0.35 A
• Noise Level: 53 dB(A) at 3 m
• Ingress Protection: IPX4 (terminal box IP54)
• Insulation: Double insulated, no earth required
• Duct / Flange Size: 100MM (4" Inch)
• Maximum Air Temperature: 55°C extracted air
• Casing Material: Zinc-plated steel with high high-resistance motor support
• Mounting: In-line duct mounting with integrated bracket
• Overall Length (A): 287 mm (28.7 cm)
• Spigot Diameter (B): 98 mm nominal 100MM (4" Inch)
• Body Length (F): 242 mm (24.2 cm)
• Overall Height (G): 282 mm (28.2 cm)
• Weight: 2.7 kg
• Country of Manufacture: Italy
• Warranty: 1-year replacement (manufacturer conditions apply)

• [1] x Oerre Turbo Centrifugal Inline AC Fan - 100MM (4" Inch) | w/ Metal Casing
