Oerre Turbo Centrifugal Inline AC Fan - 125MM (5" Inch) | w/ Metal Casing
Air Flow 400 M³/H | Power 60W | Noise 52 dB(A) | IPX4
Product Overview
| Model Number | Turbo 125 |
| Airflow (M³/H) | 400 |
| Duct Flange Size | 125MM (5" Inch) |
| Motor Type | AC |
| Exhaust Fan Power (W) | 60 |
| Noise Level | 52 dBA |
| IP Rating | IPX4 |
| Power Cord | No - Installation must be carried out by a qualified electrician. |
| Backdraft Damper | No |
| Voltage | 240V - 1 Phase |
| Humidistat | No |
| Thermostat | No |
| Speeds / Control | Optional |
| Smart Control (Wi-Fi/App) | No |
| Run On Timer | No |
| Warranty | Fanco - 2 Years Replacement Warranty |
Description
Description
The Oerre Turbo Centrifugal Inline AC Fan 125MM with metal casing is a powerful high pressure inline solution for ducted exhaust systems. With up to 400 M3/H airflow, this Italian made centrifugal inline fan is ideal for bathrooms, kitchens, laundries and light commercial spaces where standard axial fans lose performance on longer duct runs.
The zinc plated steel casing and ball bearing motor are designed for continuous operation, while IPX4 protection, double insulation and an IP54 terminal box make it a solid choice for demanding Australian conditions. The 125MM (5" Inch) spigots connect straight to common duct sizes and the integrated mounting bracket makes installation simple in tight roof spaces and ceiling voids.
Tradies and builders will appreciate the 285 Pa pressure rating, 60W motor and 52 dB(A) noise level, providing a reliable balance of power and comfort. Pair it with quality duct, grilles and a speed controller to build a robust inline exhaust system that is easy to maintain. Add this Oerre Turbo 125 centrifugal inline fan to your cart today.
Features
Features
- High-pressure airflow - 400 M³/H centrifugal inline fan suited to long or restrictive duct runs.
- Durable metal casing - zinc-plated steel housing for commercial-grade reliability on site.
- Standard 125MM connections - 125MM (5" Inch) duct spigots to suit common Australian duct systems.
- Efficient ball bearing motor - 60W single-phase motor at approximately 2530 RPM for strong airflow and long service life.
- Moisture resistant - IPX4 protected product with IP54 terminal box and double insulated construction.
- Easy installation - integrated mounting bracket and suspension holes for quick fixing in roof spaces and plant rooms.
- High temperature capability - rated for extracted air up to 55°C for tough ventilation applications.
- System friendly - works with speed controllers, backdraft shutters and standard inline ventilation accessories.
Specifications
Specifications
- Brand: Oerre
- Model: Turbo 125 (0037300)
- Type: Centrifugal inline AC exhaust fan
- Air Flow: 400 M³/H (free air)
- Max Static Pressure: 285 Pa (29 mm H₂O)
- Power Consumption: 60W
- Voltage: 220-240V AC
- Frequency: 50 Hz
- Motor: Single phase, 2 pole, ball bearing centrifugal motor
- Motor Speed: 2530 RPM
- Nominal Current: 0.38 A
- Noise Level: 52 dB(A) at 3 m
- Ingress Protection: IPX4 product, IP54 terminal box
- Insulation: Double insulated, no earth required
- Duct / Flange Size: 125MM (5" Inch)
- Maximum Air Temperature: 55°C extracted air
- Casing Material: Zinc-plated steel frame with high-resistance motor support
- Mounting: In-line duct mounting with integrated bracket and suspension holes
- Overall Length (A): 287 mm (28.7 cm)
- Spigot Diameter (B): 123 mm nominal 125MM (12.3 cm)
- Body Length (F): 242 mm (24.2 cm)
- Overall Height (G): 282 mm (28.2 cm)
- Bracket Hole Spacing (H): 12 mm (1.2 cm)
- Weight: 2.8 kg
- Country of Manufacture: Italy
- Warranty: 1-year replacement (manufacturer conditions apply)
What's in the box
What's in the box
- [1] x Oerre Turbo Centrifugal Inline AC Fan - 125MM (5" Inch) | w/ Metal Casing
